Motor, brake, & encoder- used w/ S-controller
Select a Part for Details:
3 - USP32743001 - ***REPLACED BY KIT, KM51039078R01*** BRAKE,8.25",MAGNET,90V,
3 - US68573001 - ***REPLACED BY KM50315930R01*** BRAKE,MAGNET,12.25"W/SENSR
10 - US48873003 - NUT,HEX,G2,PLATED, 3
11 - US48731003 - WASHER,LOCK,SPRING, 3
15 - US19501108 - BELT,3L 310 FRAC HP V
16 - USP34701001 - ENCODER,MTG,ESC,90/120 FPM. BRACKET AND WHEEL ONLY. ENCODER IS US96210001
16 - USP34701002 - ENCODER,MTG,ESC,100/133FPM. BRACKET AND WHEEL ONLY. US96210001 IS THE ENCODER
18 - US101176 - BEARING,BALL,SGL,1.57 ***Replaces US503596***
21 - US49395009 - SCREW,HHC/G2,1/2-13, 2-1/2
23 - US48873005 - NUT,HEX,G2,PLATED, 1/2-13
24 - US94614002 - RING,ENCODER MAGNET MOUNTING
Click to Enlarge
×
